Otostephanos jolantae nov.sp.
Otostephanos jolantae: whirling (1).

Otostephanos jolantae: ventral view, broad lumbar / lower back ?region (arrowhead) (26.4.2012) (1).

Otostephanos jolantae; dorsal view, lower back fold (arrowhead) (26.4.2012) (1).

Otostephanos jolantae; showing spurs / foot and trophi (28.04.2012) (1).

Otostephanos jolantae; (28.04.2012) (1).

Otostephanos jolantae; contracted (28.04.2012) (1).

Otostephanos jolantae; focus on foot (28.04.2012) (1).

Otostephanos jolantae; focus on foot plate? (28.04.2012) (1).

Otostephanos jolantae; (28.04.2012) (1).

Otostephanos jolantae; (28.04.2012) (1).
Otostephanos jolantae; (28.04.2012) (1).

Otostephanos jolantae; 4 aspects of the head ; upper right: focus on the upper lip (26/28.04.2012) (1).

Otostephanos jolantae; mastax /trophi with dental formula 6/6. (5.5.2012) (1).

Otostephanos jolantae; spurs (Sp) with small triangle (arrowhead) (28.04.2012) (1).

Otostephanos jolantae; foot (28.04.2012) (1).

Otostephanos jolantae (26.4.2012) TL: 310µ / TrL: 168 / NL: 70µ / RL: 45µ / RW: 43µ / BW: 49µ / MNW: 38µ. (1)

Otostephanos jolantae; (26.04.2012) CW 36µ / HL 33µ / HW 40µ. (1)

Otostephanos jolantae; (28.04.2012) TL: 304µ. (1)

Otostephanos sp.; (28.04.2012) Trophi (1).

Otostephanos jolantae; (06.05..2012) TL 380µ (1).

Otostephanos jolantae; (06.05..2012) Trophi (1)

Otostephanos jolantae;specimen from (2); ventral view.

Otostephanos jolantae; same specimen as above from (2); dorsal view.

Otostephanos jolantae; crop of the above images. Left: the arrows point to the buckle which is characteristic for the genus Otostephanos. Right: focal plane on the upper lip (triangle) and the cingulum (arrows).

Location: Kitzbühel, Tirol, (Sima), Moor (Samples courtesy of Angie Opitz) (1); Wahner Heide, Cologne, Germany (2)
Habitat: submerged plants/ Sphagnum (1); (2);
Date: 26.04.- 02.05.2012 (1); 07.03.2015 (2)
Identification by courtesy of Nataliia Iakovenko, University of Ostrava, Czech republic.
